paul.notebook — models and systems built from scratch, running in your browser

blog.psheon.me · English · 中文 · RSS

An interactive blog. Every article builds one thing from scratch — a CNN, a Transformer, a diffusion model, neuroevolution, a quadruped's walking policy, a SLAM system, a city of autonomous agents, a task scheduler, a path tracer, an AI composer — and ships with instruments you can train, open up and break right in the page. Apart from MuJoCo's physics in article 006, everything is written in TypeScript and runs in the reader's tab: no TensorFlow.js, no ONNX Runtime, no server. Bilingual (繁體中文 / English).

從零實作的互動部落格：每一篇都能在瀏覽器裡訓練、拆開、弄壞。CNN、Transformer、擴散模型、神經演化、 機器狗走路策略、SLAM、自己過日子的小鎮居民、任務排程器、路徑追蹤器、AI 作曲家，全部用 TypeScript 從零寫起，不靠任何機器學習函式庫， 也不靠伺服器。

Articles

№	English	中文
014	Train your own AI composer in three minutes: from noodling to calm	三分鐘訓練你的 AI 作曲家：聽它從亂彈到療癒
013	A mini Figure AI in three minutes: one camera, one arm	三分鐘打造迷你 Figure AI：只給它一顆相機、一隻手臂
012	Putting a path tracer in a 3D playground: crash a car, gun a plane, fly a helicopter	把光追放進 3D 遊樂園：體驗開車碰撞、飛機加速、直升機飛行
011	How a picture clears from snow: a WebGPU path tracer from scratch	一張圖怎麼從雪花變清晰：從零寫一個 WebGPU 路徑追蹤器
010	A task scheduler from scratch	從零打造一個任務排程器
009	A city nobody schedules — 300 people, each minding their own needs	沒有人排班的城市：300 個小人各忙各的
008	Drawing the map while finding yourself on it — SLAM from scratch	一邊畫地圖，一邊找自己
007	How a cloud of noise becomes an apple: a 3-D diffusion model trained in the browser	一團雜訊怎麼長成一顆蘋果
006	A robot dog in the browser: its walking policy is four matrix multiplications (MuJoCo WASM)	把一隻機器狗搬進瀏覽器
005	One body, two heads: a multi-task HydraNet that draws boxes and masks	一個身體，兩個頭：HydraNet
004	Training a Transformer from scratch: autodiff engine, attention maps	在瀏覽器裡從零訓練一個 Transformer
003	A neuroevolution trading squad on 2024 AAPL prices	打造神經進化交易戰隊
002	Neuroevolution: 50 birds teach themselves Flappy Bird	讓 50 隻小鳥自己學會 Flappy Bird
001	A CNN from scratch: watching a convolutional network see	從零開始的 CNN

Built with Next.js 16 (App Router, static generation) · MDX · shadcn/ui (Base UI) · Tailwind v4 · TypeScript · Three.js, MuJoCo WebAssembly and WebGPU where an article needs them. The site is a PWA: a hand-written service worker (public/sw.js) keeps articles readable offline.

Develop

pnpm install
pnpm dev          # http://localhost:3000
pnpm test         # vitest (tests/): lib/ml gradients and golden values, content and search, every article's simulation
pnpm e2e          # playwright: builds, serves and tests the site, incl. axe on every page in both themes
pnpm lint && pnpm typecheck && pnpm build

The canonical origin (RSS, sitemap, metadata, OG images) comes from NEXT_PUBLIC_SITE_URL if set, otherwise from the production domain Vercel assigns (lib/site.ts). Production sets it to https://blog.psheon.me; preview deployments take their origin from Vercel.

Branches: work on dev; main changes only through a pull request. Vercel deploys main to production and gives every pull request a preview. Where the project stands and what is in flight: docs/HANDOFF.md.

Write a post

content/posts/<slug>/
  zh.mdx          required — a post exists once this file does
  en.mdx          optional — without it, /en serves the zh text with a notice
  components/     interactive components, imported by the article itself

Frontmatter is validated at build time (lib/content/schema.ts); a bad field fails the build and names the file.

---
title: …
description: …
date: 2026-09-18
tags: [computer-vision, cnn]   # lowercase kebab-case
no: 3                          # notebook entry number
interactive: true              # optional — shows the "interactive" badge
draft: true                    # optional — built in `pnpm dev` only, never in production
---

Read docs/DESIGN.md first: the design system — tokens, components, interaction and accessibility rules, content rules and the publishing checklist.

Figure, Instrument, Sidenote and Callout are available in every article without an import. content/posts/cnn-from-scratch is a full example.

Conventions that keep pages fast and honest:

• An article's components live next to it and are imported by the MDX file, so they are code-split per article. Anything heavy that isn't needed for first paint (models, dialogs) is loaded with next/dynamic behind a placeholder of the same shape.
• A number in an article should be reproducible: measured in a test, by a script under docs/research/, or live in the reader's browser. Say which.
• Inside an Instrument, titles are <p>, not headings; instruments can appear before the article's first h2.

Layout

Path	What lives there
content/posts	The articles; each one's interactive components live beside it
lib/ml	Dependency-free ML: tensor ops and an inference Sequential; neuroevolution; a reverse-mode autodiff engine (matrix and image ops, every one checked against finite differences); a decoder-only Transformer; Adam
lib/rt	The path tracer for the light series: scene, BVH, a CPU reference and the WebGPU kernel
lib/content	Post index, frontmatter schema, table of contents, reading time, the operator count on the home page
lib/search.ts	Full-text index builder and ranking (substring matching, so Chinese works)
lib/seo.ts, lib/site.ts	Canonical URLs, hreflang and Open Graph basics; the site's origin
lib/og	Open Graph card renderer (subsets a CJK font at build time)
lib/i18n	Locales and typed UI dictionaries
lib/three.ts	The named three.js exports the 3D figures use, so the bundle can be trimmed
components/site	Header, home page (hero, post bento, previews), search palette, PWA install and service worker
components/article	Article chrome: table of contents, reading progress, footer
components/lab	The Instrument frame and shared instrument parts
components/rt	The path tracer's stage, worker and React hook
components/mdx	Prose components
components/ui	shadcn/ui components, plus layout primitives ported from Launch UI
styles/launch-ui.css	Glass, fade and hairline utilities from Launch UI
public/sw.js	The service worker (network first for pages, cache first for immutable assets)
scripts/train-mnist	One-off PyTorch training for article 001; exports weights and golden values for the tests
scripts/music	Packs article 014's chorales and its trained composer into public/posts/music-ai/*.bin
scripts/light	Packs the light series' assets (the playground, the vehicles, the character and its clips) into public/posts/light-playground/*.bin: geometry, skeleton and names only, never a texture
tests	Vitest suites, grouped by library and by article
e2e	Playwright smoke tests and axe accessibility checks
docs/research, docs/reviews	Measurements and notes behind article decisions; editorial and external reviews

Retrain the digit classifier with:

uv run --with torch --with torchvision --with numpy python scripts/train-mnist/train.py

Performance and accessibility budget

Measured with Lighthouse on a production build (mobile preset, throttled): accessibility, best practices and SEO at 100; performance in the high 80s to mid 90s; about 0.5 MB per page; no layout shift. Chinese is set in system fonts on purpose: CJK web fonts cost about 2 MB and 220 KB of render-blocking CSS and took first paint from 1.2 s to 14 s.

Credits

Layout primitives and CSS utilities adapted from Launch UI. AAPL price data in the trading article is daily closing prices for 2024. The Lite3 robot model and walking policy in article 006 come from DEEP Robotics; their licences are in public/lite3/. The light series' playground is the geometry of Sketchbook's world by Jan Blaha (MIT); its textures are not used and world.glb is never committed. Article 014 trains on Craig Sapp's digital edition of Bach's 370 four-part chorales (CC BY-NC-SA 4.0); the tokens and the trained model in public/posts/music-ai/ are derived from it and carry the same licence.
